Low-profile 4-port Server-grade Gigabit PoE+ Card with 2 kV Surge Protection
- Low-profile form-factor for installation in 2U server
- 4x ports by Intel® I350-AM4 server-grade GigE controller
- Compliant with IEEE 802.3at to deliver 25.5 W each port
- IEC 6100-4-5 Class 3 surge immunity
- Supports 9.5 kB jumbo frame, teaming and IEEE 1588
- Per-port PoE+ power on/off control by software API
Product Highlights
Applications
Surveillance & security
Machine vision & AOI
Medical imaging
Field communication
Specification
PCIe-PoE334LP
Bus Interface x4, Gen2 PCI Express Gigabit Ethernet Port 4x GigE ports by Intel® I350-AM4 controller,
supporting 9.5 kB jumbo frame, teaming and IEEE
1588PoE Capability In compliant with IEEE 802.3at-2009 (PoE+), each port
delivers up to 25.5 W of power 75W total power
budget (due to power limitation of PCI Express bus)Cable Requirement CAT-5e or CAT-6 cable, 100 meters maximal Power Requirement Maximal 1.2 A @ 3.3 V from PCI Express bus
Maximal 6.2A @ 12 V from PCI Express busEMC CE Class A, according to EN 55022/55024
FCC Class A, according to FCC Part 15, Subpart BEMS IEC 61000-4-x Class/Level 3 Operating Temperature 0°C ~ 55°C with air flow Dimension 167.7 mm (W) x 68.9 mm (H)
